POUCH MAKING MACHINE

SKU: HS-250

From $33,061.00

Simple to use and compact in size, this machine is ideal for making pouches on demand. Just by changing the roll width and entering the pouch length you can make a large variety of pouches as needed. You no longer have to be concerned about inventory levels or waiting for pouches to be made. This unit is ideal for medical devices requiring simple to use, on demand pouches. Each pouch can be printed with lot, date, and serial number codes along with other printed information. Eliminates the concerns of having properly printed information with each pouch. The unit can be set up to run on demand or in automatic mode producing the quantity required.

Impulse seal technology is used to provide an excellent quality seal that is validatable. Roll stock material enters the impulse heat seal station. After being sealed the material is pulled to length by servo driven rollers. After being cut to length, the pouch leaves the fully guarded unit.

  • Make on demand pouches, reduce inventory
  • Simple to use, compact in size
  • Only requires 230 VAC; no air required
  • Validatable impulse seal
  • Heat Seal Width: 9” bags
  • Heat Seal Length: 50mm [2”] minimum to 2,540mm [100”] maximum
  • Temperature Range: 10 – 300°C [50-572°F]
  • Power: 230 VAC
  • Size: 610mm [24”]W x 610mm [24”]L
  • Plow fold unwind to use single ply heat seal material
  • Thermal printer (requires compressed air)
  • Ink jet printer
  • Laser marking system (when no ink is permitted)
  • Validation Package

Heat sealable materials including:

  • Flashspun high-density polyethylene fibers
  • Polyester film
  • Foil
  • Nonwovens
  • Paper
  • Poly tubing

Build Your Product in Minutes From AZCO Corp.

Build & Price

SKU: HS-250

POUCH MAKING MACHINE

Total Price:

Standard Seal - SKU: SSEAL

$0.00
Single 10mm [0.39"] Seal

Chevron Seal - SKU: CHEV

$5,050.00
Make a single chevron seal with the flat seal to be added later.

Printing - SKU: NP

$0.00
No printing

Inkjet Printer - SKU: PRINTINK

$15,997.00
Provides the ability to print on the material before it is cut.

Thermal Printer - SKU: PRINTTHERM

$28,855.00
Includes all mounting and interfaces. Print color is black.

Laser Marker Head - SKU: LASER

$88,376.00
Includes PLC controls, integration, testing, and setup.

Flat Material Option - SKU: FLATMAT

$8,271.00
Enables open-ended bags to be made from flat sheet material.

Material Flow Package - SKU: MFP

$3,832.00
The laminar air flow helps feed the material and guide it, preventing any static charging to the base of the knife assembly.

Stainless Steel Cutting Blades - SKU: SSB

$970.00
This will change the cutting blade material from D2 tool steel to 400 series stainless steel.

Double Sided Tape Station - SKU: DOUBTAPE

$9,660.00
Enables unit to apply maximum 1” wide double-sided tape after the heat seal station.

Sealing Bar Validation Package - SKU: VALID

$19,416.00
A thermal couple will be added to the unit for temperature confirmation and calibration.

Material Handling - SKU: ST-HS250

$3,832.00
Static Eliminator

Jam Sensor - SKU: HS-JE-1

$939.00
Unit automatically shuts down when no product is sensed exiting the knife assembly indicating an internal jam.

No Product Sensor - SKU: 221990NP1

$939.00
Unit automatically shuts down when no product is sensed entering the rollers.

Eye Registration - SKU: HS-RE

$3,390.00
Enables pre-printed film to be run on the machine.

Unwind - SKU: HS250D-01

$0.00
Basic Drag

Power - USA - SKU: 110USA

$0.00
110VAC 50-60 HZ Single Phase

Power - USA - SKU: 220USA

$0.00
220VAC 50-60 HZ SINGLE PHASE

Power - Other Country - SKU: 220OC

$57.00
220VAC 50-60 HZ Single Phase
